White Rabbit CAD

and it's more for use your rabbit as "tools" for replace 2D progs when vectorial export will be existing!
because some people say me WHoooa how smooth ergonomic drawing curves against illustrator (that i have not - i have Moi & Aff Designer)

Bravo for the DXF !

have you an example or that ? "write your own geometry in a text editor, copy the text and paste it into White Rabbit"
very intrigating
something like "circle 13, x=7, y= 8" ?

[Taron]

Something like that, yes, but a bit more cryptic, because it's not "meant to be edited" at this point. Scripting comes later!
Right now (after the update) you would have to write, for example...

TOOLS:
Circle -20.000 -23.500 94.847 0.900 0.000 0 0x000000ff 2 1
Bezier -88.000 -40.500 -42.000 -63.500 -82.500 -56.250 -71.000 -62.000 -59.500 -67.750 false 0.900 0.000 0 0x000000ff 2 1 -1 -1
Bezier 6.000 -65.500 43.000 -46.500 20.250 -69.750 29.500 -65.000 38.750 -60.250 false 0.900 0.000 0 0x000000ff 2 1 -1 -1
Line -102.000 -20.500 -76.000 8.500 0.900 0.000 0 0x000000ff 2 1
Line -76.000 8.500 -40.000 24.500 0.900 0.000 0 0x000000ff 2 1
Line -40.000 24.500 7.000 24.500 0.900 0.000 0 0x000000ff 2 1
Line 7.000 24.500 35.000 6.500 0.900 0.000 0 0x000000ff 2 1
Line 35.000 6.500 59.000 -23.500 0.900 0.000 0 0x000000ff 2 1

You would have to know what is what, but it's not so hard to figure out for the most part. The "0x000000ff", for example, is the color in Hex code and this one is Black at 255 opacity. General logic is always: Name of "tool" start.x start.y end.x end.y width dashes capStyle color internalInfoWIdth internalInfoDash
Again, this is all deliberately not meant to be read or edited, while you can. Later on we will have really scripting, where it's no longer cryptic like that.

Well i doubt that i use it in this actual form!

I attack Dart, Spread, Pivot!

[Taron]

Oh god...I'm bracing myself!

OK all is mastered!
Except textures who are resisting!
And not very clear when its possible to draw something and why in the Tab Base or not ...
Strategy is open a new Tab...

Bug ? Seems a simple circle can't be "extracted" ?
a circle trimed by a curve yes!

simple _circle.jpg (4.54 KiB) Viewed 6167 times

[Taron]

Yes, you cannot and must not cut a circle! You can, but should not, make a circle out of an arc, just like you did before already, which then can be extracted, but is not meant to be. No viable clothing pattern ever is a circle, you know. ...I know, it's weird from an art point of view, but it makes perfect sense in this context.

https://www.self-couture.com/jupe-cercle/




PS When you said export PDF, that must also say Import PDF ?

[Taron]

Have I not mentioned import PDF? Thought I did, hmm... but, yes, import PDF is there, too.
The above is a "circle skirt", and you can immediately see that it is half a circle, AKA arc! You can extract arcs without a problem!
